Electric Pneumatic Tie Wrap Cutting Tool With Auto Bundle Function Colloect Waste Material
Handheld cable tie gun is easy to operate. There are 4wheels to move easily. It takes 1.0seconds to bundle one cable tie so is useful to save at least 3 workers labor cost.
SWT36150H advantages
1 . Dealing with cable ties W3.6 * L150mm. They are loose cable ties.
2 . Be easy to operate. Once push the trigger, the cable tie gun would automatically bundle products with zip ties.
3 . With automatically detect function. If it is not successful to bundle the cable tie such as wrong operation cause, it would stop and deal with the failed cable tie. Then it works normally.
4 . Be comfortable to hold and operate the gun head.
5 . The tightening force is adjustable.
6. Max bundle diameter is 31mm for wires.
7. Min bundle diamter is 3mm.
SWT36150H basic data
| Name | Cable tie machine | Model | SWT36150H | Using type | Handheld |
| Cable tie type | Loose cable tie | Cable tie width | 3.6mm | Cable tie length | 150mm |
| Size of host machine | L890 * W900 * H790mm | Weight of host machine | 160kg | Material | Metal |
| Size of gun head | L271 * W116 * H74mm | Weight of gun head | 0.90kg | Certificate | CE |
| Electric power | AC220V, 50 / 60Hz | Power | 1000W | Pneumatic pressure | 5kg / cm² |
SWT36150H technical specifications
| Bundling Max Dia. for wire / tube | Ø31mm / Ø 30mm | Bundling Min Dia. | Ø3mm |
| Operation speed | 1.0S | Actual pneumatic pressure | 3 - 5 kg / cm² |
| Temperature | 40℃ | Qty of cable ties per time in vibration bowl | 200 – 300pcs |
Applications
Rail transportation sector
Electrical installation
Wiring harness
Package
The machine would be packaged in wooden cases. One for the machine, the other one is for the vibration bowl.
| SWT36150H automatic cable tie gun packing details |
| The host machine / wooden case | Weight/kg | 175kg |
| Packing Size/cm | L101 * W105 * H91cm |
| The vibration bowl / wooden case | Weight/kg | 91kg |
| Packing Size/cm | L81 * W71 * H107cm |
| Total G.W. | 266kg( estimated) |
Our service
Before sales service – our professional sales man will reply you in time and give the suggestions.
After sales service
1 . We offer 1 year warranty and tech support forever.
2 . We offer online guide on guiding you operate the machine. In China mainland, we can go to your factory and install the machine for you.
FAQ
1. What is the warranty?
1year.
2. What is MOQ?
MOQ: 1pcs
3. Can I use other cable ties in this machine?
No, one cable tie, one machine.
We were in Wire harness show.
